Product Features
- Available in 2 meter sections
- Extruded aluminum construction
- Anodized matte finish
- Consult factory for custom lengths & finishes
Technical Specifications
| Model | CH-211 |
|---|---|
| Length | 78.74″ (2m) |
| Overall Width | 0.75″ (19.5mm) |
| Internal Width | 0.688″ (16.9mm) |
| Height (Square) | 0.75″ (19.2mm) |
| Height (Round) | 0.75″ (18.8mm) |
| Height (Flat) | 0.5″ (12.4mm) |
| Pivot Clip Height @ 90° | 1.125″ (28.5mm) |
Product Dimensions
Instructions
IES Files
Frosted Lens
Photometric Reports
Frosted Lens
Product Description
Create uniform, suspended lines of light without the hassle of cable suspension.
Documents and Links
Dimensions
Ordering Information
